Optical Tables, Breadboards & Workstations

Optical Tables, Breadboards & Workstations

From TMC; standard or customised optical tables, breadboards workstations and vibration isolation solutions for all for all photonics & lifescience requirements - from confocal microscopy and interferometry to Petawatt lasers. Proprietary designs for highest stiffness and isolation ...
› Read More

List  Grid

Set Descending Direction
per page
  1. TMC STACIS III Vibration Cancellation System

    TMC STACIS III Vibration Cancellation System

    Designed to filter out floor motion using inertial vibration sensors and piezo actuators with complex control algorithms. Can be used in series with air damped supports to completely cancel environmental vibration at low and high frequencies.

    • Hundreds of times stiffer than air isolators – STACIS suffers from none of the limitations of air vibration isolation systems. There is no "soft" suspension and, unlike active air systems, STACIS can be placed beneath a tool with an internal active air isolation system with both systems fully optimized.

    • The unique serial design and proprietary high-force piezoelectric technology –  results in a wide active bandwidth from 0.6 Hz to 150 Hz and unmatched, truly active vibration isolation with 90% vibration reduction starting at 2 Hz.
    Learn More

    View

  2. TMC CleanBench Laboratory Table

    TMC CleanBench Laboratory Table

    Vibration isolated lab equipment tables for a wide range of applications including scanning probe microscopy, confocal microscopy, interferometry and optical metrology.

    • Unique new table-top design (patent pending) combines the best features of TMC's CleanTop steel honeycomb tops with our ultra-stiff, damped, layered platform design.
    • Greater stability, especially for small size tables. The low profile, high density tops lower the overall floating center-of-mass ensuring inherently stability, even for relatively top-heavy payloads.
    • Guided thread lead-ins to align screws with tapped holes. The "bevel" shape eases engagement of the first thread.
    • Ergonomics optimized for the seated user by minimizing the thickness of the table-top. Other designs either offer 100 mm, 4 in. thick tops which awkwardly separate knees and elbows or sacrifice essential mass by offering a 50 mm, 2 in. thick honeycomb top which does not have adequate massfor effective vibration isolation, especially for smaller table sizes.

    Learn More

    View

  3. TMC CleanTop Optical Table Performance Series

    TMC CleanTop Optical Table Performance Series

    Industry-leading performance resulting from the highest core density and smallest honeycomb cell area in an all-steel construction. Three performance levels and multiple options available.

    • All steel construction – No particle board sidewalls or plastic layer between top skin and honeycomb core. Assures maximum strength and structural integrity.

    • Smallest core cell size, highest core density – The CleanTop design does not require enlarging the steel honeycomb core cell size because CleanTop cups are cylindrical, not conical as found in plastic layer designs. CleanTop's average cell size of 0.5 in.(2) is at least 50% smaller than that achieved with plastic layer designs assuring the highest stiffness and greatest core-to-skin bonding contact area.

    • Steel to steel to steel – CleanTop achieves a spill-proof core with only two bonding layers: top skin to core and core to bottom skin. Imitations must add a third bonding layer which weakens the structure: top skin to plastic layer, plastic layer to core, and core to bottom skin.

    • Thermal stability – The CleanTop all steel construction assures materials of identical coefficient of thermal expansion ensuring optimal thermal stability.

    Learn More

    View
