RIGOL PLA3204 Logic Analyzer Probe for MHO Series

Previous Next

Availability: In stock

Product Code:

78297

Manufacturer: Rigol

£159.00 £190.80

The New RIGOL PLA3204 Logic Analyzer Probes for MHO Series offer complete flexibility. Each probe has 4 channels and four grounds. Each pod is supplied with 6 leads and 6 probe clips.

1 x PLA3204 – 4 Logic probes with grounds leads.
2 x PLA3204 – 8 Logic probes with grounds leads.
3 x PLA3204 – 12 Logic probes with grounds leads.
4 x PLA3204 – 16 Logic probes with grounds leads.

Specifications

Technical Specifications	PLA3204
No. of Input Channels	4
Threshold Range	±15 V
Threshold Accuracy	±(100 mV + 3% of \|threshold setting\|)
Max. Input Voltage	±40 V (peak)
Max. Input Dynamic Range	±10 V + threshold
Min. Voltage Swing	500 mVpp
Min. Detectable Pulse Width	5 ns
Input Impedance	100 kΩ ± 1%
Input Capacitance	About 11 pF
Cable Length	About 120 cm
Lead length	About 25 cm
