Sensepeek 6013 SQ100 - 100 MHz Handsfree Oscilloscope Probe
One complete handsfree 100 MHz oscilloscope probe that makes instant measurements or long triggering sessions a breeze.
- Passive 10:1 probe
- Spring-loaded test needle for fine pitch measurements
- Multiple ground options
- Colour coded cable holders
- Probe tip protection
- Insulated, can be used handheld
- Improved probe holder for handsfree measurement when used with PCBite PCB holders
- The Sensepeek SQ100 can be used hands free or removed for quick probing around your PCB.
The new Sensepeek SQ series of handsfree probes from Sensepeek have a lower point of gravity making them even more stable compared with the original SP series of handsfree probes. All probes in the SQ series are also insulated and can be used handheld as any traditional probe but their full potential is used when measuring handsfree.
All the loved features of handsfree measurement, exchangeable fine pitch spring tipped test needle, color-coded cable holders and the minimalistic design is maintained to make traditional sized and handheld probes obsolete.
Both length and weight of the SQ probes are perfectly balanced to be used with PCBite PCB holders and base plate which is a must for handsfree function.
Includes:
- 1x SQ100 100 MHz probe with spring tipped test needle
- 1x SQ probe holder for handsfree measurement
- 1x Test hook with detachable cables (5cm & 10cm) for convenient ground connection
- 1x Alligator cable for convenient ground connection
- 1x Standard ground spring, for handheld measurements at rated bandwidth
- 1x Unique ground spring, for total handsfree measurements at rated bandwidth
- 1x Set of colour coded cable holders(4 colours)
- 1x Probe tip protection
- 1x Extra test needle
|
Model |
||||||
|
Coupling |
AC |
DC |
AC |
DC |
AC |
DC |
|
Nominal division ratio |
10:1 |
|||||
|
Bandwidth (-3dB), (note 1) |
> 1.5 GHz |
> 3 GHz |
> 6 GHz |
|||
|
Output Connector |
BNC |
SMA |
SMA |
|||
|
Max. usable data rate (fundamental) |
3 Gbps |
6 Gbps |
12 Gbps |
|||
|
Max. usable data rate (3rd harmonic) |
1 Gbps |
2 Gbps |
4 Gbps |
|||
|
Max. usable data rate (5th harmonic) |
0.6 Gbps |
1.2 Gbps |
2.4 Gbps |
|||
|
Transition time (note 2) |
< 190 ps |
< 103 ps |
< 52 ps |
|||
|
Probe tip impedance, nominal |
500 Ω |
500 Ω |
333 Ω |
|||
|
Probe tip capacitance, typical, (note 3) |
0.35 pF |
0.35 pF |
0.35 pF |
|||
|
Probe tip capacitance, maximum (note 4) |
1.36 pF |
1.69 pF |
1.31 pF |
1.25 pF |
0.69 pF |
0.69 pF |
|
Return loss for probed line |
max < -10 dB typically -26 dB to -11.0 dB in the range 0 - 1.5 GHz |
max < -10 dB typically -26 dB to -11.5 dB in the range 0 - 1.5 GHz |
max < -3 dB typically -26 dB to -3.70 dB in the range 0 - 3 GHz |
max < -4 dB typically -26 dB to -4.30 dB in the range 0 - 3 GHz |
max < -6.1 dB typically -23 dB to -6.2 dB in the range 0 - 6 GHz |
max < -5.8 dB typically -23 dB to -6 dB in the range 0 - 6 GHz |
|
Accuracy for line Z0 = 36 ohm to 60 ohm (note 6) |
0.2 dB |
0.2 dB |
0.2 dB |
0.2 dB |
0.3 dB |
0.3 dB |
|
Accuracy for line Z0 = 0 ohm to 100 ohm (note 6) |
0.83 dB |
0.83 dB |
0.83 dB |
0.83 dB |
1.2 dB |
1.2 dB |
|
Nominal error for line Z0 = 50 ohm (note 6) |
0.424 dB |
0.424 dB |
0.424 dB |
0.424 dB |
0.629 dB |
0.629 dB |
|
Nominal error for line Z0 = 75 ohm (note 6) |
0.628 dB |
0.628 dB |
0.628 dB |
0.628 dB |
0.927 dB |
0.927 dB |
|
Continues voltage |
6.6 V AC RMS |
16.4 V RMS |
6.0 V AC RMS |
15.2 V RMS |
6.3 V AC RMS |
13.0 V RMS |
|
DC blocking voltage (max) |
50 V DC |
- |
50 V DC |
- |
50 V DC |
- |
|
Peak voltage (note 5) |
±60 V DC, 30 V AC RMS, ± 42.4 V pk max. |
|||||
|
Pulse width at peak voltage |
- |
- |
- |
- |
< 500 ns |
|
|
Duty cycle pulse at peak voltage |
- |
- |
- |
- |
< 1:48 (2.08%) |
|
|
Low-frequency cut off (-3dB) (note 7) |
377 Hz |
- |
359 Hz |
- |
536 Hz |
- |
|
Flatness (+/- 0.5dB) |
1.0 kHz to 1.5 GHz |
0 to 1.5 GHz |
1.0 kHz to 2.6 GHz |
0 to 2.7GHz |
1.15 kHz to 4.8 GHz |
0 to 5.2 GHz |
|
Output impedance (nominal) |
475 Ω |
475 Ω |
76 Ω |
|||
|
Output return loss |
- |
< -10 dB up to 5.5 GHz -8 dB @ 6 GHz |
||||
|
Ringing max (+/-) |
0.33 dB @ 1.5 GHz |
0.33 dB @ 1.5 GHz |
0.14 dB @ 3 GHz |
0.125 dB @ 3 GHz |
0.065 dB @ 3 GHz, 0.15 dB @ 6 GHz |
0.05 dB @ 3 GHz, 0.26 dB @ 6 GHz |
|
Additive voltage noise @ 23 deg C (note 3) |
110 µV |
110 µV |
156 µV |
156 µV |
180 µV |
180 µV |
|
Single GND Bandwidth (-3dB) |
1.5 GHz |
1.5 GHz |
2 GHz |
2 GHz |
- |
- |
|
Nominal probe tip pitch |
Dual GND 2.3 mm / Single GND 6.5 mm |
Dual GND 3.5 mm |
||||
|
Group delay (+/-) |
- |
6ns +/-1ns (+/-1.5ns up to 4GHz) |
||||
|
Environment |
|
|
Operating temperature range |
0 - 50 °C |
|
Storage temperature range |
-20 to 70 °C |
|
Temperature range for stated specifications |
15 - 30 °C |
|
Max. humidity, operating (non-condensing) |
80 % to +30 °C, decreasing linearly to 40 % at +50 °C |
|
Max. humidity, storage (non-condensing) |
80 % |
|
Max. altitude Operating |
2 km |
|
Pollution degree |
2 (As defined in IEC 61010-031. Only non-conductive pollution. Occasionally, however, a temporary conductivity caused by condensation must be accepted.) |
|
Safety |
CAT 0, IEC 61010-31:2022 |
|
EMC approvals |
Not applicable |
|
Environmental approvals |
WEEE, RoHS |
|
General |
|
|
Supplied accessories |
Probe holder for handsfree measurement, storage case, cable holders, replacement tip needle, dual ground needle, single ground spring (not included in 6.0 GHz models) |
|
Cable length with probe and connector |
1200 mm |
|
Dimensions (probe head) |
Length 90 mm, Ø 8.9mm |
|
Weight with probe and cable |
34 g |
All specifications are subject to change without notice.
note 1, Measured, The probes can continue to measure above the rated bandwidth but with decreased signal, the probe will reach the f3dB limit above the rated bandwidth.
note 2, Calculated 10% - 90%
note 3, Calculated
note 4, Measured
note 5, WARNING Signals exceeding the voltage limits in the table below are defined as "hazardous live" by EN 61010.
note 6, Simulated
note 7,Limit with sinus, (square wave will be flat from kHz)
