Data Acquisition & Data Loggers

Keysight 34970A Data Acquisition / Data Logger Switch Unit

• 3-slot LXI data acquisition unit with 6 ½-digit DMM (22-bit) and 8 plug-in modules to choose from
• Measures 11 different input signals including temperature with thermocouples, RTDs and thermistors; DC/AC volts or current; 2- or 4-wire resistance; frequency and period
• Accepts all 34970A switch and control plug-in modules, and is backward compatible with the 34970A SCPI command set
• 1Gbit LAN and USB 2.0 for easy connectivity to the PC
• USB memory port for data storage or transfer
• Graphical Web interface for easy set up and control
• Free BenchLink data logger software to create tests without programming

Get the new next-generation 6.5 Digit data acquisition (DAQ) system from Keysight, with a 3-slot mainframe and your choice of 8 plug-in modules with new high speed solid state module. Interface with the DAQ using Keysight BenchVue DAQ software, the intuitive graphical front panel with task oriented, self-guiding menus, or a web browser.

DrDAQ Kit comprising DrDAQ, 2 temperature sensors, 1 pH sensor, 1 humidity sensor and 1 oscilloscope probe. The Pico Technology DrDAQ is a versatile instrument that connects to the USB port of any PC.  Using the supplied PicoScope software it can be used as an oscilloscope, spectrum analyser and signal generator.

Data Acquisition Mainframe with DMM Module, 20 channel MUX module, and M3TB20 terminal block
Discounted as Ex-Demonstration unit

For a limited time only, purchase the Pico TC 08 and receive 2 Pico Type K, exposed tip, 1 meter, PTFE Insulated Thermocouple Sensors absolutely free of charge! (worth £14) Choose from the dropdown box below:

Temperature measurement and logging. Monitor between 1 and 8 thermocouples, and you are ready to go. The Pico Technology TC-08 Thermocouple Data Logger offers industry–leading performance and is an inexpensive answer to your temperature measuring needs.

Download the NEW PicoLog 6 now for free, from https://www.picotech.com/download.

Keysight 34972A LXI Data Acquisition / Data Logger Switch Unit

• 3-slot LXI data acquisition unit with 6 ½-digit DMM (22-bit) and 8 plug-in modules to choose from
• Measures 11 different input signals including temperature with thermocouples, RTDs and thermistors; DC/AC volts or current; 2- or 4-wire resistance; frequency and period
• Accepts all 34970A switch and control plug-in modules, and is backward compatible with the 34970A SCPI command set
• 1Gbit LAN and USB 2.0 for easy connectivity to the PC
• USB memory port for data storage or transfer
• Graphical Web interface for easy set up and control
• Free BenchLink data logger software to create tests without programming

The Keysight 34980A is a flexible, reliable switching and data acquisition platform offering 6.5 digit accuracy and eight slots and more than 21 modules to help you customize your test system to your exact needs.

• The Keysight DAQA194A dual lock link kit is compatible with the Keysight DAQ970A, 34970A, and 34972A data acquisition systems, the Keysight 34460A, 34461A, 34465A, 34470A, and 34420A DMMs.

• Rack cabinet: System II or System II Plus

• Rack cabinet: System II or System II Plus

• 40 Channel Single-Ended Multiplexer
• Single-wire switching for common-low applications
• 100 channels/s scanning
• Built-in thermocouple reference junction

• 16 bits of digital input and output
• 100 kHz totalizer input
• Two +/-12V analog outputs plus two voltage/current sensing channels

• Dual 4 Channel RF Multiplexer
• 2 GHz bandwidth, 50 Ohm
• Cascade together for up to 16:1 multiplexer

• 4 x 8 Matrix Switch
• 32 two-wire cross points
• 300 V, 1 A switching

• 20 Channel Actuator/General Purpose Switch
• SPDT (Form C) latching relays
• 300 V, 1 A actuation and control

• 16 Channel Multiplexer
• Two- and four-wire scanning
• 250 ch/s scanning
• Built-in thermocouple reference junction

• 20 Channel Multiplexer + 2 Channels for dedicated current measurement
• Two- and four-wire scanning
• 300 V switching
• 80 channels/s scanning
• Built-in thermocouple reference junction

• 20 Channel solid-state multiplexer
• Two- and four-wire scanning
• 120 V switching
• 450 channels/s scanning
• Built-in thermocouple reference junction

The Pico Technology EL032 is a replacememt 3 meter sensor cable for DrDAQ sensors.

LIMITED TIME OFFER - SAVE 10%

Price was £342 now £308 - limited availability

MC3132 Rigol 32 Channel Multiplexer Module

LIMITED TIME OFFER - SAVE 10%

Price was 60 now £54 -Limited availability

M3TB32 Rigol 32 Channel MUX Terminal Box

Data Acquisition Mainframe with DMM Module, 32 channel MUX module, and M3TB32 terminal block.

The Pico Technology DrDAQ is a versatile instrument that connects to the USB port of any PC.  Using the supplied PicoScope software it can be used as an oscilloscope, spectrum analyser and signal generator.

The Pico Technology DD100 is a high-accuracy general-purpose thermistor temperature sensor with a two-meter lead for use with the DrDAQ Data Logger. Suitable for air, surface or liquid measurements.

The Pico Technology PP163 DrDAQ humidity sensor is designed for the cost-effective measurement of relative humidity. When plugged into one of the external sensor sockets on DrDAQ (using the supplied 3 m cable) readings can be displayed in %RH. The sensor has a response time of 60 seconds and can operate over a 0 to 60 °C temperature range.

Measuring pH using DrDAQ is achieved using the Pico Technology DD011 pH electrode which plugs in to the dedicated BNC connector on the DrDAQ logger. It covers the full 0 to 14 pH range, and its robust epoxy body makes ideal for educational use. The electrode comes complete with a small bottle of storage solution to help prevent it drying out.

The DrDAQ redox sensor (also known as an ORP sensor) can measure redox potential in the range of –1500 mV to +1500 mV. Positive readings indicate an oxidizing agent (addition of oxygen), while negative readings indicate a reducing agent (reduction of oxygen).

Pico Technology MI029 BNC plug to 4 mm (banana) plug cable, 1.2 m.

The Pico Technology PP216 Magnetic Induction Kit provides a simple and effective method for students to investigate the concepts of Faraday’s laws of electromagnetic induction. A small bar magnet is dropped down the tube and, as it passes through the coil, an electromotive force (EMF) is induced. The output pulse can be viewed using a Pico Technology PC Oscilloscope, a DrDAQ data logger or most other types of digital storage oscilloscopes.
