Sampling oscillloscope kits for signal integrity measurements and characterisation of RF components, SERDES devices, cables, PCBs, and connectors.

• 20 GHz bandwidth, 17.5 ps transition time
• 0.064 ps time interval resolution, jitter < 2.0 ps rms + 20 ppm delay
• 16-bit resolution and < 2.0 mV rms noise
• 2.5 GHz trigger bandwidth or 14 GHz pre-scaled trigger bandwidth
• Industry-leading sampling rate 1 MS/s, trace length up to 32 kS
• Integral signal generator: Pulse, PRBS NRZ, PRBS RZ, 500 MHz clock, Meander, Trigger out
• Eye diagram, eye line, histograms and mask test on NRZ and RZ serial data
