Dome Lighting

Dome lights allow a highly shadow free lighting and avoid reflections from polished objects whilst also able to highlight detail (or contamination) on curved, rough and bumpy surfaces. For highly reflective surfaces they perform better than standard ring lights. The best evenness of light will be achieved as close as possible to the object. These lights provide an economical source of diffused light and are available in a wide range of sizes (inner diameter 44–348 mm). The dome lights are housed in a black aluminium ring. These dome lights are available in a wide range of sizes. As an option the CD hole (camera hole) can be covered by an adapter in order to reduce the hole size. These lights are available in red, white, blue, green, IR and UV. Special RGB lights are built with high-power three-chips LED; red, green, and blue.

Enabling the use of each colour separately or in combination. From these units white lights can be achieved by setting each channel to the same intensity level. The available dimensions and working distances of the RGB option remains the same as the standard ring lights. For all RGB lights 4 channel controllers are required.

See Technical data sheet for further details:

Technical data for the range of Dome lights

For further customisation of units and capable specification adjustments

Dome Lighting

Product	Colour	Dimensions	Product
Monster Light High Brightness LED IR 940 Dome Lights - MDL7.25-940	IR 940	140mm	Dome Light	>
Monster Light High Brightness LED IR 850 Dome Lights - MDL7.25-850	IR 850	184mm	Dome Light	>
Monster Light High Brightness LED Red Dome Lights - MDL7.25-630	Red	184mm	Dome Light	>
Monster Light High Brightness LED Amber Dome Lights - MDL7.25-590	Amber	184mm	Dome Light	>
Monster Light High Brightness LED Green Dome Lights - MDL7.25-530	Green	184mm	Dome Light	>
Monster Light High Brightness LED Cyan Dome Lights - MDL7.25-505	Cyan	184mm	Dome Light	>
Monster Light High Brightness LED Blue Dome Lights - MDL7.25-470	Blue	184mm	Dome Light	>
Monster Light High Brightness LED UV 395 Dome Lights - MDL7.25-395	UV 395	184mm	Dome Light	>
Monster Light High Brightness LED UV 365 Dome Lights - MDL7.25-365	UV365	184mm	Dome Light	>
Monster Light High Brightness LED White Dome Lights - MDL7.25-WHI	White	184mm	Dome Light	>
LED Dome Light Outer Diameter 348mm	-	-	-	>
LED Dome Light Outer Diameter 202mm	-	-	-	>
LED Dome Light Outer Diameter 162mm	-	-	-	>
LED Dome Light Outer Diameter 102mm	-	-	-	>
LED Dome Light Outer Diameter 78mm	-	-	-	>
LED Dome Light Outer Diameter 44mm	-	-	-	>
