Electronic Loads

Electronic Loads

DC electronic loads provide you with the flexibility to test a wide range of applications from power-supply test to simulation of high-intensity discharge (HID) headlamps. The 16-bit voltage, current and power-measurement system provides both accuracy and convenience, and eliminates the ...
› Read More

List  Grid

Set Descending Direction
per page
  1. Rigol DL3021 200 Watt Electronic Load

    Rigol DL3021 200 Watt Electronic Load

    Excl. VAT: £399.00 Incl. VAT: £478.80

    Rigol DL3021 programmable 200W DC electronic load

    • Total Power 200W
    • Max Current 40A
    • User Interface Monochrome
    • Max Slew Rate 2.5 A/μs Standard
    • Max Frequency 15KHz
    • Resolution 1 mA Standard
    • Digital I/O Optional
    • Ethernet Optional
    Learn More

    View

  2. Keysight 82357B USB-GPIB Interface Converter

    Keysight 82357B USB-GPIB Interface Converter

    Excl. VAT: £452.00 Incl. VAT: £542.40
    The Keysight 82357B USB/GPIB Interface provides a direct connection from a USB port on your laptop or desktop PC to GPIB instruments. There are no switches to set, no PC cards to install, and no external power supplies required. Learn More

    View

  3. AIM-TTi LD400 DC Electronic Load, 400W, 80V, 80A, Analogue Control

    AIM-TTi LD400 DC Electronic Load, 400W, 80V, 80A, Analogue Control

    Excl. VAT: £902.00 Incl. VAT: £1,082.40

    The AIM-TTi LD400 DC Electronic Load offers 80V-80A-400W with front panel control and monitoring.

    • Constant current, resistance, power, voltage and conductance
    • Transient generator, variable slew rate, soft start
    • Current monitor output, analogue remote control
    • Front and rear input terminals
    • Built-in transient generator with variable slew
    • High resolution backlit graphic LCD with soft key control
    • USB, RS-232, GPIB and LAN interfaces (P - Programmable Models)
    • Three models available, LD400 with analogue front panel control and LD400P with programmable digital interfaces or the programable LDH400P offering 400W upto 500V or 16Amps.
    Learn More

    View

  4. AIM-TTi LD400P Programable DC Electronic Load, 400W, 80V, 80A, Analogue and Digital Control

    AIM-TTi LD400P Programable DC Electronic Load, 400W, 80V, 80A, Analogue and Digital Control

    Excl. VAT: £1,065.00 Incl. VAT: £1,278.00

    The AIM-TTi LD400P DC Electronic Load offers 80V-80A-400W with front panel control and Full bus control via USB, RS232, GPIB and LXI compliant LAN interfaces.

    • Constant current, resistance, power, voltage and conductance
    • Transient generator, variable slew rate, soft start
    • Current monitor output, analogue remote control
    • Front and rear input terminals
    • Built-in transient generator with variable slew
    • High resolution backlit graphic LCD with soft key control
    • USB, RS-232, GPIB and LAN interfaces (P - Programmable Models)
    • Three models available, LD400 with analogue front panel control and LD400P with programmable digital interfaces or the programable LDH400P offering 400W upto 500V or 16Amps.
    Learn More

    View

  5. AIM-TTi LDH400P Programable Electronic DC Load, 500V, 16A, 400W with analogue and digital control

    AIM-TTi LDH400P Programable Electronic DC Load, 500V, 16A, 400W with analogue and digital control

    Excl. VAT: £1,185.00 Incl. VAT: £1,422.00

    The LDH400P DC Electronic Load offers 500V-80A-400W with front panel control and Full bus control via USB, RS232, GPIB and LXI compliant LAN interfaces.

    • Constant current, resistance, power, voltage and conductance
    • Transient generator, variable slew rate, soft start
    • Current monitor output, analogue remote control
    • Front and rear input terminals
    • Built-in transient generator with variable slew
    • High resolution backlit graphic LCD with soft key control
    • USB, RS-232, GPIB and LAN interfaces (P - Programmable Models)
    • Three models available, LD400 with analogue front panel control and LD400P with programmable digital interfaces or the programable LDH400P offering 400W upto 500V or 16Amps.
    Learn More

    View

  6. Rigol DL3021A 200 Watt Electronic Load

    Rigol DL3021A 200 Watt Electronic Load

    Excl. VAT: £690.00 Incl. VAT: £828.00

    Rigol DL3021A programmable 200W DC electronic load

    • Total Power 200W
    • Max Current 40A
    • User Interface Colour
    • Max Slew Rate 3.0 A/μs Standard
    • Max Frequency 30KHz
    • Resolution 0.1 mA Standard
    • Digital I/O Standard
    • Ethernet Standard
    Learn More

    View

  7. Rigol DL3031 350 Watt Electronic Load

    Rigol DL3031 350 Watt Electronic Load

    Excl. VAT: £871.00 Incl. VAT: £1,045.20

    Rigol DL3031 programmable 400W DC electronic load,

    • Total Power  400W
    • Max Current  60A
    • User Interface   Monochrome
    • Max Slew Rate  2.5 A/μs Standard
    • Max Frequency  15KHz
    • Resolution  1 mA Standard
    • Digital I/O  Optional
    • Ethernet  Optional
    Learn More

    View

  8. Rigol DL3031A 350 Watt Electronic Load

    Rigol DL3031A 350 Watt Electronic Load

    Excl. VAT: £1,299.00 Incl. VAT: £1,558.80

    Rigol DL3031A programmable 400W DC electronic load

    • Total Power 400W
    • Max Current 60A
    • User Interface Colour
    • Max Slew Rate 3.0 A/μs Standard
    • Max Frequency 30KHz
    • Resolution  0.1 mA Standard
    • Digital I/O Standard
    • Ethernet Standard
    Learn More

    View

  9. N3301A 600 Watt DC Electronic Load Mainframe

    N3301A 600 Watt DC Electronic Load Mainframe

    Excl. VAT: £1,700.00 Incl. VAT: £2,040.00
    The Keysight N3301A is a half-rack width mainframe with 2-slots that accepts combinations of N330x user-installable load modules (150 W to 600 W) for easy system configuration and future reconfiguration. The N3301A holds up to two N3302A, N3303A, N3304A, and N3307A load modules, or one N3305A and N3306A load modules, allowing up to 600 watts of total maximum power. Learn More

    View

  10. N3300A 1800 Watt DC Electronic Load Mainframe

    N3300A 1800 Watt DC Electronic Load Mainframe

    Excl. VAT: £1,997.00 Incl. VAT: £2,396.40
    The Keysight N3300A is a full-rack width mainframe with 6-slots that accepts combinations of N330x user-installable load modules (150 W to 600 W) for easy system configuration and future reconfiguration. The N3300A holds up to six N3302A, N3303A, N3304A, and N3307A load modules, or up to three N3305A and N3306A load modules, allowing up to 1,800 watts of total maximum power. Learn More

    View

  11. N3302A 150 Watt Electronic Load Module

    N3302A 150 Watt Electronic Load Module

    Excl. VAT: £1,394.00 Incl. VAT: £1,672.80
    The Keysight N3302A is a 150 W (0-30A, 0-60V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications. The N3302A load module is fast and accurate, for programming in constant current, constant voltage, or constant resistance modes, or for making voltage, current or power measurements. Learn More

    View

  12. N3303A 250 Watt Electronic Load Module

    N3303A 250 Watt Electronic Load Module

    Excl. VAT: £1,982.00 Incl. VAT: £2,378.40
    The Keysight N3303A is a 250 W (0-10A, 0-240V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications. The N3303A load module is fast and accurate, for programming in constant current, constant voltage, or constant resistance modes, or for making voltage, current or power measurements. Learn More

    View

  13. N3304A 300 Watt Electronic Load Module

    N3304A 300 Watt Electronic Load Module

    Excl. VAT: £1,724.00 Incl. VAT: £2,068.80
    The Keysight N3304A is a 300 W (0-60A, 0-60V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications. The N3304A load module is fast and accurate, for programming in constant current, constant voltage, or constant resistance modes, or for making voltage, current or power measurements. Learn More

    View

  14. N3305A 500 Watt Electronic Load Module

    N3305A 500 Watt Electronic Load Module

    Excl. VAT: £2,542.00 Incl. VAT: £3,050.40
    The Keysight N3305A is a 500 W (0-60A, 0-150V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications. The N3305A load module is fast and accurate, for programming in constant current, constant voltage, or constant resistance modes, or for making voltage, current or power measurements. Learn More

    View

  15. N3306A 600 Watt Electronic Load Module

    N3306A 600 Watt Electronic Load Module

    Excl. VAT: £2,445.00 Incl. VAT: £2,934.00
    The Keysight N3306A is a 600 W (0-120A, 0-60V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications. The N3306A load module is fast and accurate, for programming in constant current, constant voltage, or constant resistance modes, or for making voltage, current or power measurements. Learn More

    View

  16. N3307A 250 Watt Electronic Load Module

    N3307A 250 Watt Electronic Load Module

    Excl. VAT: £1,847.00 Incl. VAT: £2,216.40
    The Keysight N3307A is a 250 W (0-30A, 0-150V) electronic load module for use in either the N3300A or N3301A electronic load mainframe in system applications. The N3307A load module is fast and accurate, for programming in constant current, constant voltage, or constant resistance modes, or for making voltage, current or power measurements. Learn More

    View
