Optical T&M

Tunable Directional Coupler Series (TC1400) utilises all fibre, polished directional couplers with variable coupling ratio.

Polarisation Controller Series (PC1000) is designed with precision in mind.

Multi-Channel Polarisation Controller (PC1200) was designed to meet the increasing needs of polarisation control in WDM/DWDM systems.

Motorised Polarisation Controller (PC1300), this mini motorised polarisation controller (MPC) is based on FiberPro's unique fibre technology.

In-Line Polarisation Controller (PC1100) PC1100 is suitable for fibre optic systems and experiments where ismall size is especially needed.

Fibrepro Polarisation Scramblers (PS3000) These polarisation scramblers use Fiberpro's unique birefringence modulator enabling very high speed polarisation scrambling.

PDL meter (PL2000) can measure polarisation dependent loss (PDL) and insertion loss (IL) simultaneously with the worlds fastest measurement speed typically 0.1sec)!

The LUNA OBR 4600 is the industrys only ultra-high resolution OTDR with Raleigh backscatter-level sensitivity (better than -130 dB) designed for precision analysis of fiber optic components optical modules and optical sub-assemblies.

• Easily locate, identify and troubleshoot macro-bends, splices, connectors and breaks
• Locate Insertion Loss points at every point in the network or assembly – eliminate cut-back
• Look inside components to evaluate each interface for RL and IL
• Measure 30 m with 10 μm resolution in less than 7 seconds
• Continuously measure a 1 m segment at up to 3 Hz
• Test and troubleshoot short-run networks (< 2 km)
• Automate pass/fail verification of fiber assemblies
• Monitor distributed temperature and strain profiles along network or inside a component or module

This system has been replaced by the new LUNA 6415 Lightwave Analyser with improved specifications, improved user interface and much smaller system size.

Benchtop Optical Backscatter Reflectometer OBR 5T-50:

Industry-leading combination of measurement speed,range and accuracy
10 Hz acquisition speed
8.5 metre measurement range
20 micron spatial resolution
0.015% length measurement accuracy
Streamlined Graphical User Interface + Software Development Kit included
Optimise throughput with customised interface
Automatically locates reflective events and yields RL, IL and event location

• Single measurement, all-parameter analysis of devices up to 150m in length
• Full C and L band characterisation in under 3 seconds
• High resolution C and L band or O band capability
• Complete polarisation response
• Real-time measurements
• User-friendly interface

HPR Performance Reference Cables

SAVE 15% on all High Performance Reference Cables. For a limited time, stock up on this essential element of your test setup at a discounted rate – including 24-fiber fanout cables and non-BIMMF cables.

• Dynamic Range: over 80 dB
• Scan range: 600 mm (400 mm in fiber)
• Spatial Resolution: down to 10 μm
• Compact & Lightweight
• Built-In Light Source
• Performs functions of discontinued Agilent 8504B Reflectometer- and more!

• Wide wavelength range
• High PDL accuracy
• High channel-to-channel uniformity
• User friendly control program

• The DGD-1000 can generate DGD up to 400ps
• DGD-1000 has very low PDL over DGD generation range (PDL max: 0.3dB, typical: 0.1dB)
• DGD-1000 has very low IL variation over DGD range (typical 0.1dB)
• Slow SOP variation (<1 rad/min)
• Small DGD variation vs time (<0.1ps over 8 hours)
• An extended version can cover up to 600ps as special order

• High speed SOP scrambling with SOP change rate up to 11 M rad/s
• Scrambling with Rayleigh rate distribution
• Discrete SOP scrambling
• SOP modulation
• Low IL, PDL, PMD, and AL
• Bright OLED display

• Quasi-uniform rate SOP scrambling with SOP change rate up to 360 krad/s
• Scrambling with Rayleigh rate distribution
• Discrete SOP scrambling
• SOP modulation
• Low IL, PDL, PMD, and AL
• Bright OLED display

• High Resolution
• Wide Range
• Low Residual PMD
• PDL Scanning

• All digital design - no motors
• High speed PMD switching: 1 ms
• 1^st and 2^nd order PMD source/emulator
• Polarisation scrambling

• Reset free operation
• External feedback ports
• Tunable operation parameters
• Low insertion loss

• Simple, reset free operation
• PM output
• Low insertion loss

• 0.02 dB power stability (1 hr.)
• 0.05 degree temperature stability
• Flexible modulation
• Low and high DOP options

The Luna 6415 is a fast and simple-to-use analyser for passive optical components and modules. The Luna 6415 measures and analyses the Insertion Loss (IL) and Return Loss (RL) distribution, as well as length, working in either reflection or transmission.

• 20 μm sampling resolution
• 20 m measurement range
• 6 Hz scan/acquisition rate
• 1.5pm wavelength accuracy

• Fully integrated Benchtop System
• C-Band 1515nm to 1565nm
• Built-in wavemeter
• 2 optical receiver ports

• OEM-Style Module
• C-Band 1515nm to 1565nm
• Built-in wavemeter
• 2 optical receiver ports

High quality-price ratio solution for Telecommunication applications, the APEX AP201x Series is equiped with PM Optical Input and the high resolution of 20 MHz/0.16 pm. Optical spectrum analyzer (OSA) ideal for industry application to characterise active or passive component.

Available options:

• optical output of the built-in Tunable Laser Source (TLS), tracking generator function;
• SM/PM input switch, which lead to polarization independent measurement

Ideal solution for Telecommunication applications, the APEX Optical Spectrum Analyzer (OSA) AP206x Series is equipped with the high resolution of 20 MHz/0.16 pm, as well as other resolution bandwidth from 140 MHz to 250 GHz. With two polarisation channels inside, analysis of optical signal in different polarisation axis is possible.

Available options:

• the optical output of the built-in Tunable Laser Source (TLS), which could also be used for component analysis (tracking funciton);
• replace the Resolution BandWidth of 20 MHz by 5 MHz

High performance and cost effective solution for Telecommunication applications. The APEX Optical Spectrum Analyzer (OSA) AP207x Series is equiped with the high resolution of 5 MHz/0.04 pm, 20 MHz/0.16 pm, 100 MHz/0.8 pm, as well as other resolution bandwidth from 140 MHz to 250 GHz. Analysis of optical signal in both polarization axis is possible due to the two polarization channels inside. The direct access to each channel is available.

Available options:

• the optical output of the built-in Tunable Laser Source (TLS), which could also be used for component analysis (tracking funciton);
• additional grating based OSA for fast sweep, and optical filtered ouput;
• polarimeter

Top of the line APEX High-Resolution Optical Spectrum Analyzer (OSA), the AP208x Series is equiped with the high resolution of 5 MHz/0.04 pm, 20 MHz/0.16 pm, 100 MHz/0.8 pm, as well as other resolution bandwidth from 140 MHz to 250 GHz. Analysis of optical signal in both polarization axis is possible due to the two polarisation channels inside.  Thanks to the external-cavity tunable laser source inside, the scan speed is much faster than other model.

Available options:

• the optical output of the built-in Tunable Laser Source (TLS), which could also be used for component analysis (tracking function);
• additional PM inputs for each polarization channel;
• optical filtered ouput + polarimeter;

• Up to 4M samples/s
• 1 MHz analog bandwidth
• 45 dB input power dynamic range
• Real-time Poincaré Sphere display
• High-speed SOP generation and tracking
• High speed analog output of SOP & DOP
• Data logging of SOPs changes up to 1 billion point

• Multiple polarisation control modes
• Low IL, PDL, PMD, and AL
• Bright OLED display

The SUMIX MAX-QM+ is a white-light and phase-shift interferometer for inspection of MT, MT-RJ, MTP®/MPO (PC and APC), SMA connectors/ferrules in a single scan.

The SUMIX MAX-QS+ is a white-light and phase-shift interferometer for inspection of single fibre ST, FC, SC, LC, MU, E2000™ (PC and APC), small format multi-fibre MT-RJ (PC and APC), SMA and special connectors.

The SUMIX WIZ-QS-110 is an automated interferometer for inspection of single fibre connectors, ferrules and bare fibre.

OP940-CSW is a mandrel-free insertion loss and return loss measurement system with MTP/MPO front panel connections. Designed as a compact and user friendly tool for multichannel ribbon fibre measurements without the inconvenience of fan-out cables.

OP925 is an entry level, cost-effective IL/RL meter for simplex patch cord testing using the conventional CW reflectometry RL method (all other Optotest RL systems utilise a mandrel-free pulse reflectometry technique for added performance and dynamic range). IL is measured using the standard CW method.

The Tempo Communications Fibre Optic Tool Kit provides the common tools needed to satisfy varying tasks that the fibre optic technician may encounter in a safe and effective manner. The tool kit is supplied in a rugged carry case to safely keep all tools organised for easy storage and retrieval for use. Extra pockets are incorporated to hold accessories and other tools.

The Tempo Communications Fibre Optic Tool Kit provides the common tools needed to satisfy varying tasks that the fibre optic technician may encounter in a safe and effective manner. The tool kit is supplied in a rugged carry case to safely keep all tools organized for easy storage and retrieval for use. Extra pockets are incorporated to hold accessories and other tools.

The Tempo Communications Fibre Optic Tool Kit provides the common tools needed to satisfy varying tasks that the fibre optic technician may encounter in a safe and effective manner. The tool kit is supplied in a rugged carry case to safely keep all tools organized for easy storage and retrieval for use. Extra pockets are incorporated to hold accessories and other tools.

The SUMIX MAX-Quantum is a high-end automated interferometer for inspection of single and multi-fiber connectors of MTP®/MPO, ST, FC, SC, LC, MU, E2000™ types as well as MT, MT-RJ ferrules in a single scan.

The SUMIX Manta-W+ is a revolutionary portable microscope designed for inspection of all types of single and multi-fibre optical connectors, patch cords and bulkhead, included but not limited to: MT, MPO, LC, FC, SC, CS®, E2000™, PRIZM, QSFP, ARINC, MIL Spec termini, ODC12, high-power SMA, Avim, mini-Avim and more.

• Minimal Insertion Loss and Back Reflection
• Low Residual Phase and Amplitude Modulation
• Remote Operation Wavelength Control
• Built-in RS-232, GPIB and Ethernet ports

• High spatial resolution: 6 cm
• -75 dB polarisation X-talk sensitivity
• 30 dB PER measurement range
• Large fibre measurement range: 2.6 km

• Self-calibration program to optimise DOP and SOP accuracies at arbitrary wavelengths and temperatures.
• OLED display for setup and data display
• Real time Poincaré Sphere display, Analog SOP/DOP/power output for ATE integration
• Data logging of SOP up to 1 billion points

• 30 ms Measurement Speed
• Wide Wavelength Range
• High PDL Accuracy
• OLED Display and Analog Output

• One or Two Measurement Channels
• Free Space Input
• Front Panel or Remote Control
• 50 dB PER range
• Bright OLED display
• Store and Recall Functions

• Rapid measurement
• DOP wavelength independence
• Front panel real time display
• Analog output

• Fixed crystal accuracy in a swept system
• USB removable data storage
• GPIB port for control of third party lases
• Ethernet for remote operation

Luna Technologies' newly launched OBR 6200 Series Optical Backscatter Reflectometers are the industry's highest resolution portable reflectometers for field maintenance applications. With backscatter level sensitivity, a ruggedised integrated design and touchscreen, they are ideal for testing fibre optic networks deployed in aerospace, naval, land, data-centre and industrial applications.

• 100 metres range
• No dead-zone
• 80miron spatial resolution in fibre
• Dual channel system has IP65 rating

The Tempo Communications Fibre Optic Tool Kit provides the common tools needed to satisfy varying tasks that the fibre optic technician may encounter in a safe and effective manner. The tool kit is supplied in a rugged carry case to safely keep all tools organized for easy storage and retrieval for use. Extra pockets are incorporated to hold accessories and other tools.

• Production test and QC measurements of IL, RL, PDL and Min/Max (TE & TM) IL/RL in a quick single scan.
• 1.6pm resolution and 80dB Dynamic range
• Built-in Tuneable Laser Source

In order to obtain accurate and repeatable results measuring insertion and return loss, the reference connector needs to outperform the connector under test. Reference cables from OptoTest are manufactured with reference ends that are certified to exceed the FOTP171A (A2.2.1) standard.

SAVE 15% on all High Performance Reference Cables. For a limited time, stock up on this essential element of your test setup at a discounted rate – including 24-fiber fanout cables and non-BIMMF cables.

570XL 850/1300nm LED Source

Available with ST, SC and FC connectors - please specify.
