HAROGIC Technologies PXN-400, 40GHz Portable Handheld Realtime Spectrum Analyser (RSA)
The new PXN-400 is a 40GHz ultra-portable handheld Realtime Spectrum Analyser (RSA). Weighing just 1.5 kg and with a 10.1-inch all touch screen. This is a great alternative to other handheld spectrum analysers on the market offering high performance in a small ultra-portable design. Combined with an impressive battery life over 3 hours it is an excellent choice for field testing.
- Frequency range: 9 kHz-40 GHz SHR architecture, 11-segments pre-selected filters
- Sweep speed > 500 GHz/s (RBW ≥ 300 kHz)
- Analytical bandwidth: 100 MHz (std.)
- Standard preamplifier, DANL: -161 dBm/Hz (typ.)
- SSB Phase Noise: -107 dBc/Hz @10kHz (typ.)
- Weight: 1.5 kg, 10.1-inch all touch screen
- Battery life: 3h+, support power bank supply
- 3 years warranty. HDMI interface support, expandable desktop station
Real Portable · Real Performance · Real Affordable
The HAROGIC Technologies PXN-400 is the latest released 40 GHz handheld real-time time spectrum analyzer from HAROGIC Technologies. Building on continuous innovation and SWaP-C design principle, the PXN-400 offers an unmatched combination of size, performance and cost. RF measurements and analysis from 9kHz to 40 GHz is now carried out in a robust instrument with 10.1-inch full-touch screen and weighs only 1.5kg. PXN-400 is a 40GHz real-time spectrum analyser with analytical bandwidth of 100 MHz and ultra-fast speed of 500 GHz/s, delivering standard spectrum sweep (SWP), IQ streaming (IQS), zero span (DET) and real -time analysis (RTA) working mode. The PXN-400 is equipped with preamplifier and 11-segment preselector, achieving good dynamic range and phase noise level. It can provide customers with spectrum analyser, spectrum monitoring, interference finding, RF test and measurement functions.
Standard Spectrum Mode - provides standard spectrogram, waterfall graph, probability density graph, phase noise graph and other measurement graphs. It offers measurement functions such as channel power, adjacent channel suppression, occupied bandwidth, XdB bandwidth, phase noise and IM3.
IQ Streaming Mode - provides time domain and spectrum view of IQ waveform, DDC function and AM/FM demodulation function, and delivers modulation depth and modulation frequency offset test.
Power Detection Mode (Zero Span) - provides power time diagram (PvT) and its scaling, timing trigger, level trigger and other triggers.
Real-time Spectrum Analysis Mode - provides spectrum, probability density graph, waterfall graph and other measurement graphs. It offers timing trigger, level trigger and other triggers.
