AIM-TTi PSA6005USC Handheld RF Spectrum Analyzer 6.0GHz, with Option U02, Case and Accessories
Availability: In stock
Product Code:
64237
Manufacturer: Aim-TTi
£2,438.00 £2,925.60
- True hand-held battery powered RF spectrum analyzers.
- 10MHz to 3600MHz or 6000MHz frequency range
- Resolution bandwidths from 300Hz to 10MHz (1:3:10)
- -120dBm typical noise floor at -40dBm ref. level/10kHz RBW
- Measurement in dBm or dBµV, mV or µW
- Zero span mode with AM and FM audio demodulation
- Trace modes of normal, peak hold and trace average
- Live, View and Reference traces in contrasting colours
- Twin markers with readout of absolute & difference values
- Smart marker movement with selectable peak tracking
- Frequency counter with down to 10Hz resolution
- Frequency presets and independent state storage
- Auto-find automatically sets sweep parameters for the highest signal found
- Unlimited storage for waveforms, set-ups and screens
- User assignable file names, file stamping from real-time clock
- USB interfaces for Flash drives and PC connection
- Comprehensive status and context sensitive help screens
- Rechargeable lithium ion battery giving more than 3 hours continuous operation from a charge
- Smaller and lighter than other spectrum analyzers (weight only 0.56 kg)
Additional features - with option U02:
- High Resolution Scan Mode - up to 210,000 points with pan and zoom
- Limit lines and limit patterns with limits comparator
- Data logging of peak values, complete traces or screen images from timer, external trigger or limits comparator
- Automatic Measurements for CP, ACPR and OBW
- Waveform demodulation for AM and FM signals
- Sweep triggering from external trigger or limits comparator
- Compensation tables, fixed offsets and 75R compensation
- Custom Presets - fast change for repetitive setups
- Capability to show screen contents on a PC
AIM-TTi PSA Series 5 Datasheet Write Your Own Review
