Rigol DNA804 4.5GHz 2 Port Vector Network Analyser

Previous Next
Availability: In stock


Product Code:
83541
Manufacturer: Rigol
£2,383.00 £2,859.60
  • Frequency Range: 5 kHz to 4.5 GHz
  • Ports: 2-Port Architecture (N-Type Female, 50 Ω nominal)
  • Dynamic Range: Up to 125 dB (typ.)
  • Trace Noise: 0.005 dB rms / 0.035° rms (typ. 0.0015 dB rms / 0.020° rms)
  • Weight & Power: 1.9 kg | Standard USB-C PD Powered

More info and finance questions

The Rigol DNA804 is an entry level, ultra-portable vector network analyser designed for rigorous RF and microwave characterisation. Featuring a true two-port architecture and an expansive frequency coverage from 5 kHz up to 4.5 GHz, the DNA804 delivers comprehensive S-parameter (S11,S12,S21,S22) and complex impedance measurements.

Engineered for both benchtop precision and mobile reliability, the DNA804 packs up to 125 dB typical dynamic range and exceptionally low trace noise into a chassis weighing under 2 kg. Whether you are performing passive component validation, filter tuning, cable fault finding, or production-line automated testing, the DNA808 provides complete S parameter analysis capability in laboratory, field, and system integration environments.

Advanced Measurement Capability

  • Broad Frequency Range & Resolution: Spans 5 kHz to 4.5 GHz with 1 Hz frequency resolution across 1 to 100,001 sweep points.
  • Flexible IF Bandwidths: Selectable IF bandwidth from 1 Hz up to 3 MHz
  • Cascaded Expansion: True two-port architecture supporting cascade deployment of two units for expanded multi-port test configurations.
  • Time-Domain & Cable Analysis: Optional Distance-to-Fault (DTF) and Time-Domain Analysis (TDA) for impedance profiling and precise cable/connector fault locating.
  • Fixturing & De-embedding: Integrated port extension, fixture embedding/de-embedding, and limit testing (Pass/Fail) directly on the instrument.

Calibration & Precision Options

  • Electronic Calibration (ECal): Full support for the ECAL300 and ECAL400 series electronic calibration kits (N-type and SMA connectors covering up to 14 GHz) for fast, repeatable, plug-and-calibrate operations.
  • Mechanical Calibration Support: Fully compatible with precision mechanical calibration kits supporting SOLT, Response Short, Response Open, OSL, and Enhanced Response calibration routines.

Interface & Remote Operations

  • Intuitive Multi-Touch UI: 7-inch capacitive HD display (1024×600) with gesture controls, supporting physical buttons, mouse, and keyboard input.
  • HDMI Output: Connect directly to standard external displays for high-definition visual analysis during design reviews or teaching environments.
  • WebControl Architecture: Driverless remote control via any standard browser—simply input the instrument's IP address to operate or debug SCPI commands.
  • Standard SCPI Command Set: LAN and USB connectivity supporting full automated test integration with mainstream command set compatibility.



Additional Information

Specification
Ports2
ConnectorN-Type (f)
SeriesDNA800
  DNA814 DNA808 DNA804
Frequency Range 5 kHz to 14 GHz 5 kHz to 8.5 GHz 5 kHz to 4.5 GHz
Ports 2 2 2
Connector N-type Female N-type Female N-type Female
Input Impedance 50 Ω (nom.) 50 Ω (nom.) 50 Ω (nom.)
Dynamic Range 125 dB (typ.) 125 dB (typ.) 125 dB (typ.)
Trace Noise 0.005 dBrms 0.005 dBrms 0.005 dBrms
IF BW 1 Hz to 3 MHz 1 Hz to 3 MHz 1 Hz to 3 MHz

Dynamic Range
  Frequency Range Specification Typical
  100 kHz to 10 MHz 100 dB 110 dB
  10 MHz to 6.5 GHz 115 dB 125 dB
  6.5 GHz to 10 GHz 111 dB 121 dB
  10 GHz to 12 GHz 109 dB 119 dB
  12 GHz to 14 GHz 107 dB 117 dB

System Performance after Error Correction (Calibration)
Calibration Error with Mechanical Calibration Kit ECAL100/200
  Frequency Range Directivity Load Match Source Match Transmission
Tracking		 Reflection
Tracking
  5 kHz to 100 kHz 46 dB 35 dB 30 dB ±0.30 dB ±0.30 dB
  100 kHz to 10 MHz 55 dB 48 dB 45 dB ±0.06 dB ±0.08 dB
  10 MHz to 4.5 GHz 50 dB 42 dB 38 dB ±0.10 dB ±0.08 dB
  4.5 GHz to 8.5 GHz 42 dB 35 dB 30 dB ±0.15 dB ±0.10 dB
  8.5 GHz to 14 GHz 40 dB 32 dB 30 dB ±0.18 dB ±0.10 dB

Calibration Error with Mechanical Calibration Kit ECAL300/400
  Frequency Range Directivity Load Match Source Match Transmission Tracking Reflection Tracking
  5 kHz to 100 kHz 35 dB 30 dB 28 dB ±0.30 dB ±0.30 dB
  100 kHz to 10 MHz 55 dB 45 dB 42 dB ±0.06 dB ±0.10 dB
  10 MHz to 4.5 GHz 50 dB 42 dB 35 dB ±0.15 dB ±0.10 dB
  4.5 GHz to 8.5 GHz 42 dB 35 dB 30 dB ±0.18 dB ±0.15 dB
  8.5 GHz to 14 GHz 40 dB 30 dB 30 dB ±0.22 dB ±0.15 dB

Calibration Error with Mechanical Calibration Kit 85054D
  Frequency Range Directivity Load Match Source Match Transmission Tracking Reflection Tracking
  5 kHz to 100 kHz 35 dB 30 dB 25 dB ±0.30 dB ±0.30 dB
  100 kHz to 10 MHz 55 dB 50 dB 48 dB ±0.02 dB ±0.04 dB
  10 MHz to 4.5 GHz 50 dB 45 dB 38 dB ±0.02 dB ±0.04 dB
  4.5 GHz to 8.5 GHz 42 dB 37 dB 34 dB ±0.02 dB ±0.04 dB
  8.5 GHz to 14 GHz 40 dB 35 dB 34 dB ±0.02 dB ±0.08 dB

System Performance Without Error Correction/Calibration
  Frequency Range Directivity Load Match Source Match Transmission Tracking Reflection Tracking
  5 kHz to 100 kHz 20 dB 12 dB 20 dB ±1.5 dB ±1.5 dB
  100 kHz to 10 MHz 25 dB 15 dB 25 dB ±1.5 dB ±1.5 dB
  10 MHz to 4.5 GHz 25 dB 15 dB 25 dB ±1.5 dB ±1.5 dB
  4.5 GHz to 8.5 GHz 25 dB 15 dB 25 dB ±1.5 dB ±1.5 dB
  8.5 GHz to 14 GHz 25 dB 15 dB 25 dB ±1.5 dB ±1.5 dB

Test Port Output Frequency Characteristics
Frequency Characteristics
  Aging Rate <1 ppm/year
  Temperature Stability <0.5 ppm 0℃  to 40℃, with the reference 25℃
  Initial Calibration Accuracy 1 ppm
  Frequency Resolution 1 Hz
  Sweep Points 1 to 100,001
  IF BW Range 1 Hz to 3 MHz

Max. Output Power
  5 kHz to 100 kHz 0 dBm
  100 kHz to 10 MHz 5 dBm
  10 MHz to 6.5 GHz 10 dBm
  6.5 GHz to 10 GHz 6 dBm
  10 GHz to 12 GHz 4 dBm
  12 GHz to 14 GHz 2 dBm

Power Sweep Range
  5 kHz to 100 kHz -40 dBm to 0 dBm
  100 kHz to 10 MHz -40 dBm to 5 dBm
  10 MHz to 6.5 GHz -40 dBm to 10 dBm
  6.5 GHz to 10 GHz -40 dBm to 6 dBm
  10 GHz to 12 GHz -40 dBm to 4 dBm
  12 GHz to 14 GHz -40 dBm to 2 dBm
