FiberLabs S-band Amplifier (TDFA, Bench Top)

Product Code:

sband

Manufacturer: FiberLabs Inc

The FiberLabs AMP-FL8211-SB, 8221-SB and 8222-SB-PM series is S-band fibre amplifier that can produce >20 dBm output power and >30 dB gain. Having gain from 1460 to 1520 nm, this amplifier is a key enabler for the next generation high-capacity optical fibre communication beyond the C-band and L-band. The amplification with low noise figure is enabled by our proprietary fluoride fibre TDFA technology.

Description

The FiberLabs Amplifier has been used for a number of hero experiments in ultra-wideband DWDM transmission, conducted by many prestigious research institutes all over the world. The bench-top version is mainly designed for use in R&D and manufacturing environments. Now we also offer a gain-flattened model, AMP-FL8221-SB-19-W, primarily designed for S-band DWDM application.

Specifications


Product Number	Operating Wavelength (nm)	Nominal WL (nm)	Output Power (dBm)	Gain (dB) *(2)**	Gain Flatness (dB)	NF (dB)	PER (dB)	Std. Dimension (H x W x D, mm)
AMP-FL8211-SB-13	1460 to 1500	1480	≥ +13	≥ 15	N/A	≤ 7	N/A	88 x 260 x 350
AMP-FL8211-SB-16	1460 to 1500	1480	≥ +16	≥ 20	N/A	≤ 7	N/A	88 x 260 x 350
AMP-FL8211-SB-20	1460 to 1500	1480	≥ +20	≥ 25	N/A	≤ 7	N/A	88 x 260 x 350
AMP-FL8221-SB-16	1470 to 1520	1490	≥ +16	≥ 25	N/A	≤ 7	N/A	88 x 260 x 350
AMP-FL8221-SB-19	1470 to 1520	1490	≥ +19	≥ 30	N.A	≤ 7	N.A	88 x 260 x 350
AMP-FL8221-SB-19-W	1470 to 1520	1490	≥ +19	Typ.24	≤ 3 (*5)	≤ 7	N/A	88 x 260 x 350
AMP-FL8222-SB-18-PM	1470 to 1520	1490	≥ +18	Typ.24	N/A	≤ 7	≥ 20	88 x 430 x 350
