Tempo 915FS Active Cladding Optical Fusion Splicer

Previous Next

Availability: Awaiting stock
Please contact us for estimated delivery

Product Code:

64065

Manufacturer: Tempo

£2,377.44 £2,852.93

Auto-Calculation of Estimated Splice Loss
Active Cladding Technology Alignment
Selectable Heating Modes
Loose Tube to SOC Capable
Splice-on-Connector Options (SC, LC, ST & FC)
Auto-Check Fibre End Face
Transferable or Fixed Fibre Adaptors (250, 900µm)
IP 52

Description

The Tempo 915FS fusion splicer uses an active cladding alignment technology in which alignment of the fibre is performed in three axis; X, Y and Z. This allows the individual to complete fusion splices with low splice losses as with core alignment splicers and far surpassing the performance of V-Groove splicers.

The Tempo 915FS optical fibre fusion splicer is intended to fuse fibres, resulting in low splice loss and long-term stable splices. Splice loss depends on certain conditions such as fibre preparation, splicing parameters, and fibre condition.

The 915FS is perfectly suited for all FFT(x) and P2P applications.

Specifications

Specifications	915FS
Application Fibres	SMF (ITU-T G.652), MMF (ITU-T G.651), DSF (ITU-T G.653), NZDSF (ITU-T G.655, BIF (ITU-T G.657), EDF
Fibre Cleaved Length	8 to 16mm (Coating diameter: 0 to 250μm); 16mm (Coating dia. 250 to 1000μm)
Cladding Diameter	80 to 150μm
Coating Diameter	100 to 1000μm
Fibre Count	Single
Fibre Aligining Method	Active Caldding Alignment
Splice Loss (Typical)	SMF/BIF ≤0.02dB/ MMF≤0.01dB / DSF/NZDSF/EDF ≤0.04dB(typical)
Attenuated Splice Function	0.1dB - 15dB
Splicing Mode	60 Preset / User Definable Modes
Splice Time (Typical)	≤9 seconds
Splice Loss Evaluation	Yes
Fibre Check	Fibre cleaving angle / axis offset / loss / fibre alignment / focus etc.
Splice-on-Connector	LC, SC, ST and FC
Arc Calibration Mode	Automatic & Manual
Protection Sleeve Strength	60mm, 40mm, Micro Sleeves
Storage of Splice Results	5000 Splices/100 Screenshots
Tension Test	2N
Fibre Display Magnification	Dual CMOS cameras, 200x zoom
Tube Heating Time (Typical)	Auto heating 24s - 36s (28s default) and user defined
Display	3.5" Colour LCD, Auto Flip
Electrode Life	5000 arcs
Splices per Battery Charge	150+ (splice & heating) cycles
Humidity	0 to 95%
Temperature	(-25°C to 50°C)
Storage Temperature	(-30°C to 70°C)
Power Supply	110-240V AC/DC Power Adapter (50/60Hz) 4400 mAh Li-ion Battery
Weight (including Battery)	1.2kg (without battery) / 1.5kg (with battery)
Dimensions (HxWxD)	135 x 125 x 125mm
