Tempo TK052 Simple LAN Test Kit MM

Availability: In stock

Product Code:

76912

Manufacturer: Tempo

£1,526.00 £1,831.20

A simple fibre cable test kit, the right solution for low to modest test volume on multimode LAN, with some single mode capability.

Typical test applications:

Optical power at 8 calibrated λ, -60 to +10 dBm range.
Loss on MM fibre 850 / 1300 nm, 40 dB range, EF compliant.
Optical loss on SM fibre at 1300 nm, 28 dB range.
Reporting software for cable loss (manual data entry).
Optical continuity / tone source & meter with 12 Multi-Fiber ID fibre, 40 dB range.
Generally meets safety regulations & standards based test procedures.

Connector & battery summary:

Includes:

Attribute Name	Attribute Value
Detector type	InGaAs
Response wavelength	600 ~ 1700 nm
Calibration wavelengths	850, 1300, 1310, 1390, 1490, 1550, 1577, 1610, 1625 nm
Power range	+5 ~ -60 dBm
Mid-range linearity	0.04 dB (typical)
Total uncertainty	0.3 dB (max)
Wavelength sensitivity (± 30 nm)	0.03 dB (typical)
ID tone detection sensitivity	up -50 dBm
