Rigol NFP-3 Near Field Probe Kit

Previous Next
Availability: In stock


Product Code:
53980
Manufacturer: Rigol
£415.00 £498.00

Rigol NFP-3 Near Field Probe Set 30MHz to 3GHz. Includes 4 probe types, 1m lead BNC (M)-SMB (F), Adapter N-Type(M)-BNC(F), storage case.

More info and finance questions

RIGOL NFP-3 RF Near Field Probe Kit

  • Frequency Range: 30MHz to 3GHz
  • One set includes four probe types, allowing for optimised sensitivity and resolution
  • Minimum resolution: 2mm; able to capture near field radiation of a single circuit line
  • Applicable for electromagnetic leakage testing inside the cable
  • A measurement tool for EMI pre-conformance testing, troubleshooting and design verification
  • Determine frequency and relative intensity of the spectral components of the interference source

NFP-3-P1
Near field probe which can detect the magnetic field within a range of 10 cm. It is applicable for the leakage detection of magnetic field. For example, verification of shielding measuremnt, leakage testing for the chassis etc.

NFP-3-P2
Near field probe which can detect the magnetic field within a range of 3 cm. It is applicable for detecting the magnetic environment around themodules. For example, accurately locating the leakage of the chassis, detecting the magnetic field direction and intensity of the circuit board module.

NFP-3-P3
Near field probe which resolution is 5 mm. It is applicable for the detection of magnetic field on surface. For example, the detection of the magnetic field produced by the wire, cable, metal surface, connectors, electronic components and components joints.

NFP-3-P4
Near field probe which resolution is 2 mm. It can detect the vertically emitted electromagnetic field. It is applicable for the detection of magnetic field where current loops exist. For example, electromagnetic field testing for PCB wiring, magnetic field testing for IC pins area etc.

Frequency
Frequency Range 30 MHz to 3 GHz
Terminal Type
Terminal Type SMB (M)
Adaptor N (M)-BNC (F)
RF Cable BNC (M)-SMB (F), 1000mm
Terminal and Adaptor Impedance   50 Ω
General Specifications
Dimensions 260 mm × 190 mm × 30 mm (with package)
Weight 0.425 kg (with package)
Operating Temperature 0℃ to 50℃
Temperature -20℃ to 70℃
